8.5'x22' Quality Cargo Enclosed Cargo

Standard Specifications

• 15” Tires
• Silver Mod Wheels
• 36” RV Style Side Door with Flush Lock
• V-Nose with Vertical ATP Trim
• Rear Ramp with Spring Assists and Flap
• Tandem 5200 lb Spring Axles with 4” Drop and EZ Lube Hubs
• 24” Stoneguard on Front
• White Metal Exterior
• Beavertail Frame
• 4 D-Rings in Floor
• 3/4” Plywood Floor (Painted Underneath)
• Premium 3/8” Plywood Sidewalls
• 1” × 1½” Steel Tube in Walls and Ceiling
• 78” (6’6”) Interior Height
• 2000 lb Tongue Jack
• 6” I-Beam Main Frame
• 12V Dome Light with Switch
• Non-Powered Roof Vent or Sidewall Vent
• LED Strip Tail Lights
• Wall Members 16” O.C.
• Floor Crossmembers 16” O.C.
• Roof Members 24” O.C.
• Screwed Metal Exterior
• Galvalume Roof
• 7-Way Round Electrical Plug with 2 5/16” Coupler

Structure

• V-Nose with Vertical ATP Trim
• 6” Extra Height
• 5200 lb 22½° Down Torsion Axles
• Rear Wing

Tie-Downs & Stabilizers

• 4 D-Rings
• 48' Floor E-Track (1 Row on Each Side)

Tires & Wheels

• Black Mod Wheels
• Chrome Center Lug Covers
• Sand Foot
• Radial Tires

Doors, Ramps, & Windows

• 36" RV Side Door
• Heavy Duty Rear Ramp with Flap
• 15" × 30" Window on RV Door
• 5' Ramp Door on V-Nose (Passenger Side)

Vents & A/C

• Side Vents

Exterior

• White Front / Black Rear Exterior
• Blackout Package

Interior

• Cool Seal Liner
• Plywood Trim

Electrical

• Loading Lights on Rear Wing
• 48" LED Strip Lights
